Figures in which the part appears:
3169320-ETL (Grove GMK 3055 )
3169321-ETL (Grove GMK 3055 )
3169322-ETL (Grove GMK 3055 )
3169323-ETL (Grove GMK 3055 )
3169324-ETL (Grove GMK 3055 )

Also known as:
3115197, 03115197, 003115197
Parts for Grove GMK 3060, Figure 3169321-ETL:
Part Number 3115197: CONNECTING LINK
Pos nr Part number Description Weight in kg
12 3153284 LOCK 1.520
13 3153299 LOCK 0.670
14 3080753 LOCK 1.080
15 3080705 LOCK
17 3080591 STRIP T=10 0.022
18 3080612 STRIP T=11 0.025
19 3080613 STRIP T=12 0.03
20 3080614 STRIP T=13 0.030
21 3080615 STRIP T=14 0.030
22 3080616 STRIP T=15 0.035
23 3080617 STRIP T=9 0.02
24 3080618 STRIP T=8 0.02
25 3080619 STRIP T=7 0.02
26 3080620 STRIP T=6 0.015
27 3080621 STRIP T=5 0.015
28 3080592 STRIP T=10 0.1
29 3080622 STRIP T=1 1 0.025
30 3080623 STRIP T=12 0.025
31 3080624 STRIP T=13 0.03
32 3080625 STRIP T=14 0.03
33 3080626 STRIP T=15 0.100
34 3080627 STRIP T=9 0.1
35 3080628 STRIP T=8 0.100
36 3080629 STRIP T=7 0.1
37 3080630 STRIP T=6 0.015
38 3080631 STRIP T=5 0.100
39 3080641 STRIP T=5 0.025
40 3080640 STRIP T=6 0.03
41 3080639 STRIP T=7 0.03
42 3080638 STRIP T=8 0.035
43 3080637 STRIP T=9 0.04
44 3080593 STRIP T=10 0.045
45 3080632 STRIP T=1 1 0.05
46 3080633 STRIP T=12 0.200
47 3080634 STRIP T=13 0.052
48 3080635 STRIP T=14 0.06
49 3080636 STRIP T=15 0.06
50 0437182 HEXAGON SCREW 0.120
51 0437183 HEXAGON SCREW 0.026
52 0437192 HEXAGON SCREW 0.046
54 1147382 HEXAGON SCREW 0.08
55 0437644 HEXAGON NUT 0.084
56 0119962 WASHER 0.012
57 0437529 WASHER 12 0.006
58 3066256 SHEAVE HOLDER 0.42
59 0027079 HEXAGON SCREW 0.014
60 0437642 HEXAGON NUT 0.003
62 0026283 HEXAGON SOCKET HEAD CAP SCREW 0.012
65 3080675 SLIDER 2.07
66 3080679 SLIDER 0.085
67 3080656 SLIDER 0.001
73 3176672 LOCKING
74 3115341 CONNECTING LINK 1.73
75 3115197 CONNECTING LINK 0.94
77 0105305 CIRCLIP 0.080
78 3317553 GUIDE PIN L=28, T=8 0.02
79 3317550 GUIDE PIN L=25, T=5 0.015
80 3317551 GUIDE PIN L=25, T=6 0.01
81 3317552 GUIDE PIN L=27, T=7 0.02
82 3317554 GUIDE PIN L=29, T=9 0.02
83 3317555 GUIDE PIN L=30, T=10
84 3080704 GUIDE PIN L=49; T=20
85 3080728 GUIDE PIN L=51,5; T=22
86 3080729 GUIDE PIN L=53,5; T=24
87 3080730 GUIDE PIN L=55,5; T=26
88 3080731 GUIDE PIN L=47,5; T=18
89 3080732 GUIDE PIN L=45,5; T=16
90 3080733 GUIDE PIN L=43,5; T=14
91 3320928 SCREW CONNECTION 0.260
92 0433858 LUBRICATING NIPPLE 0.001
93 3320927 HEXAGON NUT 0.01
94 2251403 EXTENSION PIECE 0.01
95 2311780 ANGLE MALE COUPLING 0.140
96 3155722 LUBRICANT HOSE
97 1685807 HEXAGON SOCKET HEAD CAP SCREW 0.035
98 0100785 HEXAGON SOCKET HEAD CAP SCREW 0.02
99 1577155 HEXAGON SOCKET HEAD CAP SCREW 0.03
100 0028195 RETAINING RING
106 3090467 SLIDER 0.220
109 3094130 GUIDE PIN L--41,5; T=12
500 3176687 SLIDERS AND PROTECTION STRIP JIB COMPONENT TELE 2
